The LM2500 High Pressure Turbine (HPT) Vertical Stand is a support fixture designed to hold the HPT module of the LM2500 gas turbine in a vertical position. It is mainly used during maintenance, inspection, or transport of the turbine module.

By keeping the turbine upright, the stand helps ensure that the module stays stable and properly aligned while work is being done. This setup also makes it easier for technicians to access certain areas of the HPT that would be harder to reach if the module were lying flat.

The stand is built to handle the weight of the HPT and includes features like mounting points or forklift slots for safe and easy movement within a workshop or maintenance area. It is commonly used in the oil and gas industry where LM2500 turbines are found in power generation or mechanical drive applications.

In short, the HPT Vertical Stand is a practical tool that helps keep the turbine secure, makes maintenance tasks safer, and supports good handling practices.

The T5.4 thermocouple is a temperature-sensing probe used in LM2500 gas turbines to measure exhaust gas temperature (EGT). The label T5.4 refers to its specific position in the turbine\'s exhaust thermocouple array—zone T5 (turbine exhaust), sensor 4. These sensors are part of a system that monitors thermal conditions at multiple points in the exhaust stream.

This thermocouple operates in high-temperature environments, withstanding continuous exposure up to approximately 1100°C. It is built to maintain accuracy and reliability under the thermal stress and vibration typical in gas turbine applications.

T5.4 thermocouples are often used with flexible

harness systems. This allows operators to replace individual probes without removing the entire harness, improving maintenance efficiency and reducing downtime.

By providing real-time exhaust temperature data, the T5.4 thermocouple supports engine control, performance optimization, and safety monitoring in industrial gas turbine operations.

The LM2500+G4 SAC 50Hz Combined Cycle 1x1 is a gas turbine system that combines a gas turbine with a steam turbine to improve overall power generation efficiency. This configuration captures waste heat from the gas turbine exhaust and uses it to produce steam, which then drives the steam turbine, generating additional electricity. This approach helps maximize power output while making better use of fuel energy.

Building on the LM2500+ design, the LM2500+G4 increases power capability by about 10% without reducing the lifespan of critical hot section components. This is achieved by increasing airflow, enhancing materials, and improving internal cooling. Despite these upgrades, the core compressor and turbine stages, as well as most airfoil and combustor designs, remain consistent with the LM2500 model.

The LM2500+G4 features a 17-stage high-pressure compressor that raises the engine’s pressure ratio and airflow, boosting the total power output of the gas turbine to over 31 MW. It uses a Single Annular Combustor (SAC) equipped with water injection to help control emissions while maintaining stable combustion. The SAC’s simple, proven design provides uniform flame temperature and reliable operation.

This balanced system is common in industrial and energy applications where efficiency and power output must be optimized, especially under varying ambient conditions. The combined cycle setup offers a reliable and efficient solution for electricity generation in demanding environments.

The 3-inch sleeve-style hot air purge valve is designed for aero-derivative industrial gas turbines to control the flow of hot compressor bleed air used in critical purge operations. This valve is normally closed and solenoid-pilot actuated, available in two- or three-inch sizes with elbow sleeve design. It operates on 24 or 125 VDC power and is constructed with ANSI B16.5 Class 600 raised face flanges.

Key specifications include a physical size of approximately 7.5 inches wide and 25 inches high, weighing between 84 to 91 pounds. It can handle line pressures up to 500 psig and actuation pressures between 80 and 125 psig. The valve is rated to operate in fluid temperatures ranging from 32°F to 1100°F (bleed air), and can withstand ambient temperatures between –20°F and 240°F with heat soak up to 400°F for 1 to 2 hours when de-energized.

Performance characteristics include a flow capacity of about 1.2 pounds per second of compressor bleed air with a maximum pressure drop of 0.70 psi across normal operating conditions. Internal leakage is minimal, rated at 0.00025 pounds per minute. The valve features a rapid full stroke response time of 1 second for both opening and closing cycles. It includes a position indicating switch and supports continuous duty operation.

Functionally, this valve plays a crucial role in purging residual fuels, such as diesel, from the combustor fuel lines when switching fuels, preventing deposits that can impair turbine performance or cause damage. The valve is often installed in pairs for dual redundancy to enhance safety and operational reliability. With millions of field operating hours, this design reflects high durability and precise control essential for efficient and safe turbine operation.

The LM2500 Gas Generator is the core component of the LM2500 gas turbine, responsible for producing the high-energy gas flow needed to drive the power turbine. It features a 16-stage axial compressor that efficiently compresses incoming air, a single annular combustor where fuel and air mix for optimal combustion, and a two-stage high-pressure turbine that extracts energy to power the compressor.

Designed for durability and high performance, the LM2500 Gas Generator supports a wide range of fuel types, including natural gas and liquid fuels, enabling flexible operation in various industrial and marine settings. Its modular construction allows for easier maintenance and faster engine removal or replacement, minimizing downtime.

With advanced aerodynamics and robust engineering, the LM2500 Gas Generator delivers reliable, efficient gas flow, helping ensure consistent power output and lower emissions across demanding operating conditions.

The LM2500+ DLE gas turbine is a high-performance solution for power generation in industrial, onshore, and offshore environments where emissions control and water availability are key concerns. Delivering over 30 megawatts of power and up to 40% thermal efficiency in simple cycle operation, it offers reliable performance with low environmental impact.

At the core of its design is the advanced Dry Low Emissions (DLE) combustion system, which reduces NOx and unburned hydrocarbon emissions without the need for water or steam injection. The system achieves this by precisely managing combustion conditions and lowering flame temperature. A triple annular combustor configuration enables fuel to burn more evenly at lower temperatures across a larger area, while new electrically actuated fuel metering valves enhance control and reduce complexity compared to older electro-hydraulic systems.

The LM2500+ DLE also features a 17-stage axial compressor for increased airflow and output, along with a modular, open design that enables faster maintenance and engine replacement. Its fast start capability makes it suitable for operations requiring multiple starts and stops per day.

Whether powering industrial facilities, pipeline networks, or combined heat and power (CHP) systems, the LM2500+ DLE offers a dependable and efficient gas turbine solution that balances operational flexibility with emissions performance.

The LM2500XPRESS+G5 DLE UPT is a modular aeroderivative gas turbine system built for fast, flexible, and efficient power generation in both onshore and offshore environments. It is particularly well-suited for applications across LNG facilities, gas pipelines, gas processing plants, and general power generation, including electricity production at both 50 and 60 Hz, without the need for a speed reducer.

The "+G5" designation refers to its fifth-generation power turbine, offering the highest output and efficiency in the 20–40 MW class. It supports both high-speed and low-speed power turbine configurations, allowing integration into a variety of grid or mechanical drive systems.

At its core, the G5 includes a high-pressure compressor derived from the LM2500+G4, now redesigned for longer service life. In a simple cycle, it achieves up to 41% efficiency, which is notable for a turbine of this size class. The system can start from cold and reach load in about five minutes, making it ideal for rapid-response applications.

The unit is built for speed and simplicity. It’s shipped in preassembled modules, with a compact footprint that helps reduce installation time.

The Dry Low Emissions (DLE) system supports environmental compliance without requiring water or steam injection, simplifying operations and reducing resource demands.

Altogether, the LM2500XPRESS+G5 DLE UPT provides a practical solution for projects that need reliable, fast, and efficient power without a complex setup.
