The HDI 1522 Choke Position Indicator System is an electronic instrument designed to accurately measure and display the position of choke valves used in oil and gas production. Choke valves regulate the flow of oil, gas, or water from wells by adjusting the degree of restriction in the pipeline, which directly affects pressure control and production rates. The 1522 system provides highly precise position readings in one percent increments, ranging from fully closed (0%) to fully open (100%), enabling better management of well performance and enhanced safety.

This system uses solid-state electronics to convert mechanical valve movement into electronic signals via various potentiometer types—including linear, rotary, and retractable options—making it adaptable to a wide variety of choke valve designs and configurations. The position data is presented on a four-inch liquid crystal display that combines a numeric readout with a linear bar graph, allowing clear and immediate visualization of the choke’s exact position. The display is engineered for visibility from distances up to fifteen feet, suitable for typical field environments.

Powered by an internal, field-replaceable battery with approximately one year of continuous operation, the 1522 system minimizes maintenance requirements and eliminates the need for complex wiring. It also offers optional analog output signals, such as 4-20 mA or 0-1 V, enabling seamless integration with plant control systems, programmable logic controllers, data acquisition systems, or remote display units for centralized monitoring and automation.

The enclosure is constructed from UV-stabilized, impact-resistant polycarbonate and PBT alloy materials to ensure durability in harsh outdoor conditions. It is rated to operate reliably within a wide temperature range from -40°F to 176°F (-40°C to 80°C). The internal electronics are protected by a gasket seal to prevent dust and moisture ingress, maintaining performance and longevity.

Installation flexibility is enhanced through support for cable lengths up to 1,500 feet, allowing the gauge to be mounted in the most accessible or secure locations. Multiple sensor housing options and connector orientations simplify field installation and reduce the need for onsite customization, helping to minimize downtime and installation costs.

The 1522 Choke Position Indicator System delivers accurate, real-time choke valve position information in a robust, easy-to-install package. Its reliable performance, flexible integration capabilities, and low maintenance design support improved flow control, safer operations, and optimized production.

The 1/2" poppet check valve with female × female NPT connections is designed to allow fluid to flow in only one direction while preventing any backflow. This is important in oil and gas systems because backflow can damage pumps, pipelines, and other equipment. The valve is commonly used in medium-sized lines, instrumentation, sampling, and control applications where reliable flow control is required.

The valve operates at a standard pressure of 6000 psi, with optional configurations available for pressures up to 10000 psi. Cracking pressures, the minimum pressure needed to open the valve, can be selected from 1/3 to 25 psi, giving flexibility to match the needs of specific systems. Its poppet mechanism responds quickly to flow changes and provides a tight seal, ensuring consistent performance and preventing leaks.

Made from corrosion-resistant materials such as SS 316, SS 316L, Duplex, Super Duplex, Hastelloy C276, Inconel 625, Monel 400, and Brass, the valve is suitable for harsh oil and gas environments. Female × female NPT connections allow for secure inline installation without extra fittings, reducing the risk of leaks and simplifying integration into existing piping.

Each valve is factory tested for cracking and reseal performance, ensuring it opens and closes reliably. Heat code traceability is provided to verify material quality. Additional testing, such as vibration, temperature, and helium testing, can be requested for applications requiring high reliability.

This valve is compact, durable, and designed for long-term operation with minimal maintenance. It helps maintain system pressure, protects critical equipment, and ensures that oil and gas systems operate safely and efficiently.

The Tube Fittings Bulkhead Male Connector NPT Thread is a specialized fitting designed to pass tubing securely through panels, enclosures, or bulkheads while maintaining a reliable, leak-tight seal. It is suitable for high-pressure applications up to 6000 PSI and is manufactured according to ASME B16.34, MSS-SP-99, and ASME B31.3 standards, ensuring safety, reliability, and compatibility with industrial systems.

Its bulkhead design allows the tubing to be firmly supported at the barrier, reducing stress on the tubing, preventing vibration-induced leaks, and providing consistent sealing performance under pressure, vacuum, or dynamic conditions.

The NPT male thread enables direct connection to piping, valves, or other threaded components, making installation straightforward and versatile. Precision-machined components ensure that ferrules deform correctly for an optimal seal, while silver-plated threads reduce friction and minimize galling during assembly. Case-hardened ferrules and a robust body material provide durability under repeated assembly or exposure to high vibration, thermal cycling, or corrosive environments.

The design also allows for easy disconnection and retightening without compromising the seal, providing flexibility for maintenance or system changes. Tubing must be properly inserted to the shoulder of the fitting body to ensure maximum sealing efficiency, emphasizing that tubing selection and handling are integral to optimal performance.

Overall, this fitting provides a reliable, high-performance solution for routing tubing through barriers in demanding industrial environments, combining ease of installation, high-pressure capability, and long-term durability with precision engineering suitable for critical oil and gas or process applications.

The Hex Nipple Pipe Fitting with Male NPT threads is a precision component used to connect two female-threaded pipes or fittings in instrumentation and process control systems. The male tapered threads create a tight, leak-resistant seal when engaged with a corresponding female NPT connection, making it suitable for high-pressure and high-temperature applications commonly found in the oil and gas industry.

Manufactured from high-quality bar stock, the fitting provides strength and durability. Threads are capped and carefully packed to prevent damage during transport. The fitting is marked with the manufacturer’s name, size, material, and heat code for traceability. The design ensures proper thread engagement, reliable sealing, and smooth flow of fluids or gases.

These fittings meet or exceed ASME B1.20.1 standards for NPT threads and are rated according to ASME B31.3 for process piping, supporting safe and consistent operation in industrial environments. The male NPT design allows easy installation while maintaining a durable, leak-tight connection over the life of the system.

The HDI 1000P Pressure Gauge System is a battery-powered, intrinsically safe electronic gauge used to monitor high-pressure systems in oil and gas operations. It measures pressure using a strain gauge sensor and provides real-time readings on a digital display with both numeric and bar graph formats. Common applications include choke manifolds, cementing units, coiled tubing, and high-pressure pumping systems.

With pressure ranges available from 5,000 psi up to 30,000 psi, the 1000P is suitable for demanding environments. It offers ±0.5% full-scale accuracy, and optional 4-20mA or 0–1 VDC outputs for integration with PLCs or remote monitoring systems. The unit is housed in a sealed stainless steel enclosure and built to perform reliably in harsh, high-vibration field conditions.

Designed for ease of use, the 1000P includes a field-replaceable battery pack and supports a range of connection types such as 2" 1502, 2002, 2202, or flanged. Its solid-state platform minimizes maintenance and ensures consistent performance over time, making it a dependable tool for critical pressure monitoring tasks.

The Ball Valve Lever Operated 3-Way Tube OD Side Entry is a high-performance valve designed to control or divert fluid flow in oil and gas piping systems. Its 3-way configuration allows fluid to be routed between multiple tubing lines, making it useful for applications such as flow diversion, sampling, injection systems, or process line bypasses.

The side entry design provides easier access to the ball and internal components for maintenance or inspection, while also allowing compact installation in tight piping layouts. The tube OD connections enable direct attachment to tubing without additional fittings, simplifying assembly, reducing potential leak points, and providing secure, inline connections.

The valve uses a floating ball design to ensure consistent, leak-proof shut-off under high-pressure conditions. Operation is simple and reliable with a quarter-turn lever, providing fast control with low torque. The internally loaded stem with shoulder prevents blowout, and replaceable seats and packings allow maintenance without replacing the entire valve.
