The 3” Tubing End Locator is a mechanical downhole tool used to identify the precise end of a 3-inch production tubing string during well intervention operations. It provides a clear physical indication when the tool reaches the bottom of the tubing, helping to ensure accurate placement of equipment inside the well.

Designed specifically for tubing with a 3-inch outer diameter, the tool features a maximum outside diameter of 2.500 inches. This sizing ensures smooth movement within the tubing while maintaining close contact, allowing the tool to operate effectively without the risk of sticking or misalignment. At the core of the design is a spring-loaded finger mechanism that extends outward when the tubing end is reached. This mechanical movement is transmitted to the surface as a tactile response, signaling that the tubing bottom has been contacted.

The tool includes standard threaded connections—such as a 15/16 - 10 UN pin on the top and a 1 - 11 ½ NPT box on the bottom—which makes it compatible with a variety of toolstring configurations. It can be easily incorporated into slickline, wireline, or coiled tubing assemblies without the need for special adapters.

Constructed from durable, corrosion-resistant materials, the tubing end locator is built to perform reliably in downhole environments that involve high pressure, elevated temperature, and exposure to fluids. Its fully mechanical operation ensures a high level of dependability and minimizes the need for maintenance, especially in conditions where electronic systems may not be suitable.

The 3” Tubing End Locator is a practical solution for confirming tubing depth when preparing the well for further intervention.

The 5 Valve Manifold T Type, Pipe to Flange is engineered to connect impulse lines to differential pressure transmitters in industrial and oil and gas applications. It features 1/2” Female NPT Pipe to Flange connections set at 54mm (2-1/8”) centers, with a configuration consisting of two block valves, two equalizer valves, and one bleed valve. This design allows for efficient isolation, calibration, and maintenance of transmitters while maintaining process integrity.

The T Type configuration is especially useful because it provides a compact and organized valve layout that simplifies operations like bleeding and equalizing, reducing the risk of leaks and measurement errors. Using a 5 valve manifold ensures maximum operational flexibility, allowing operators to isolate the instrument, balance pressure, and vent safely without interrupting the main process.

Pipe to Flange connections are chosen when connecting transmitters or instruments to existing flanged piping systems, offering strong mechanical support and compatibility with industry-standard flanges. This combination of T Type, 5 valves, and pipe-to-flange connections ensures accurate, reliable, and safe pressure measurement and calibration in critical oil and gas operations.

Coiled tubing is a continuous, flexible steel pipe widely used in well intervention and maintenance operations, allowing operators to clean, stimulate, log, or deploy tools inside the wellbore without shutting down production. This capability makes coiled tubing an efficient and cost-effective solution to maintain well health and improve productivity.

The 3 1/16” 10M Coiled Tubing Hanger is designed to support larger diameter coiled tubing and heavier tool strings required for more demanding or deeper well operations. The size “3 1/16”” refers to the wellhead bore size that the hanger fits into, while the “10M” indicates its pressure rating of 10,000 psi, meaning it is built to withstand high-pressure environments typically found in advanced well interventions.

This hanger is rated to maintain pressure containment during interventions in high-pressure wells, ensuring safe operations and protecting well integrity. It accommodates coiled tubing sizes ranging from 1 inch up to 1¾ inches outer diameter, which allows the deployment of heavier and more complex downhole tools needed for challenging well conditions. Its rugged construction is engineered to withstand mechanical stresses from heavy tool strings and high pressures without compromising performance.

Designed with flanged connections compatible with API 6B and 6BX standards, the hanger integrates seamlessly with existing wellhead equipment, simplifying installation and maintenance. An important feature of this model is the wireline entry sub, which guides wireline tools into the tubing bore, facilitating additional intervention tasks. The wireline entry sub also provides a secondary annulus seal that prevents fluid or gas leaks and restricts any upward movement of the tubing, enhancing operational safety.

The hanger maintains a secure secondary annulus seal around the tubing, which is critical for isolating pressure zones and protecting against leaks during live well operations. This versatility makes the hanger suitable for various well intervention activities such as well cleanouts, acidizing, logging, and tool deployment, particularly in situations where larger tubing and higher pressures are involved.

The 3 1/16” size strikes a balance between tubing size and wellhead bore capacity. It is larger than smaller hanger sizes, allowing operators to use coiled tubing capable of handling more demanding operational requirements. Its high-pressure rating ensures safe operation in wells where pressures can reach or exceed 10,000 psi, common in deeper or complex reservoirs.

The 4 ½ x 2 7/8” Tubing Hanger Coupling is a specialized connection component used in oil and gas wellhead systems to join two different sizes of upset tubing—4 ½-inch and 2 7/8-inch. This size combination is commonly selected when there is a need to transition from a wider tubing hanger profile to a smaller production string, without significantly restricting flow or compromising mechanical strength. The slightly larger 2 7/8” production tubing allows for greater internal flow area than smaller alternatives, making this configuration well-suited for completions that aim to support moderate to high production rates.

The coupling is designed with a union nut mechanism, which enables installation without rotating the Christmas tree or disturbing other surface equipment. This simplifies operations, especially in space-limited or sensitive surface environments. Both the top and bottom threads of the coupling can be manufactured to meet specific customer requirements, ensuring compatibility with a range of tubing string designs. Additionally, the coupling is threaded to accommodate a back pressure valve, offering an important safety feature by allowing well pressure to be managed during maintenance or pressure control procedures.

Constructed from high-grade steel and compliant with API standards, the 4 ½ x 2 7/8” Tubing Hanger Coupling offers high durability, corrosion resistance, and the mechanical integrity required for challenging downhole conditions. By supporting a secure, pressure-tight connection between tubing sizes, it plays a key role in maintaining well integrity and operational efficiency in various oil and gas production scenarios.
