The 2 1/16” 5M Coiled Tubing Hanger is designed to support coiled tubing strings in well intervention and completion work. With a 5,000 psi pressure rating, it’s well-suited for moderate to high-pressure wells, and its compact 2 1/16” size makes it ideal for smaller wellheads or space-constrained setups.

It handles tubing sizes up to 3 1/2” O.D. and is commonly used for cleanouts, stimulation, logging, and other coiled tubing operations. A built-in wireline entry sub helps guide tools into the tubing while providing an extra seal and preventing tubing movement—improving well control and operational safety.

The hanger is available with API 6B or 6BX flange connections and can include a side outlet if needed. It’s a reliable, field-proven choice for operations requiring strong support and safe access to coiled tubing tools.

The 6 5/16” to 2 1/2” Tubing Hanger Coupling is a specially made part used in oil and gas wells to connect a large casing opening to smaller tubing—typically 6 5/16 inches—to a smaller 2 1/2-inch upset production tubing. This size combination is often selected for well designs that require a broader casing interface for flow management, safety equipment, or well control hardware, while maintaining a slimmer production string for specific flow requirements or structural considerations.

This coupling is manufactured with upset-end compatibility, meaning it is suited for tubing that has thickened ends designed to strengthen threaded connections. This feature improves mechanical reliability and helps the connection withstand downhole pressure, tensile loads, and thermal cycling. The union nut design allows the coupling to be installed by tightening the nut without rotating the upper wellhead assembly, which is particularly useful in space-constrained or high-integrity environments.

To accommodate a range of operational needs, the coupling can be threaded on both ends to suit different tubing or spool designs and is compatible with back pressure valves—providing added safety during pressure control, intervention, or servicing. Built in accordance with API specifications and from high-strength materials, the coupling is designed to operate reliably in demanding conditions, including high-pressure wells and corrosive environments.

Coiled tubing is a continuous, flexible steel pipe widely used in well intervention and maintenance operations, allowing operators to clean, stimulate, log, or deploy tools inside the wellbore without shutting down production. This capability makes coiled tubing an efficient and cost-effective solution to maintain well health and improve productivity.

The 3 1/16” 10M Coiled Tubing Hanger is designed to support larger diameter coiled tubing and heavier tool strings required for more demanding or deeper well operations. The size “3 1/16”” refers to the wellhead bore size that the hanger fits into, while the “10M” indicates its pressure rating of 10,000 psi, meaning it is built to withstand high-pressure environments typically found in advanced well interventions.

This hanger is rated to maintain pressure containment during interventions in high-pressure wells, ensuring safe operations and protecting well integrity. It accommodates coiled tubing sizes ranging from 1 inch up to 1¾ inches outer diameter, which allows the deployment of heavier and more complex downhole tools needed for challenging well conditions. Its rugged construction is engineered to withstand mechanical stresses from heavy tool strings and high pressures without compromising performance.

Designed with flanged connections compatible with API 6B and 6BX standards, the hanger integrates seamlessly with existing wellhead equipment, simplifying installation and maintenance. An important feature of this model is the wireline entry sub, which guides wireline tools into the tubing bore, facilitating additional intervention tasks. The wireline entry sub also provides a secondary annulus seal that prevents fluid or gas leaks and restricts any upward movement of the tubing, enhancing operational safety.

The hanger maintains a secure secondary annulus seal around the tubing, which is critical for isolating pressure zones and protecting against leaks during live well operations. This versatility makes the hanger suitable for various well intervention activities such as well cleanouts, acidizing, logging, and tool deployment, particularly in situations where larger tubing and higher pressures are involved.

The 3 1/16” size strikes a balance between tubing size and wellhead bore capacity. It is larger than smaller hanger sizes, allowing operators to use coiled tubing capable of handling more demanding operational requirements. Its high-pressure rating ensures safe operation in wells where pressures can reach or exceed 10,000 psi, common in deeper or complex reservoirs.

The 4” Tubing End Locator is designed specifically for use with larger production tubing strings common in wells that require greater flow capacity or enhanced mechanical strength. This size is typically found in wells with higher production rates or more demanding operational requirements, where accurate depth confirmation becomes even more critical.

This model is specifically sized for 4-inch outer diameter tubing, featuring a maximum outside diameter that fits comfortably within the tubing’s internal dimensions. This sizing ensures that the locator can move smoothly without obstruction while maintaining effective contact to detect the tubing end. The core mechanism involves a spring-loaded finger that extends outward upon contacting the tubing bottom. This movement translates into a tactile signal felt at the surface, eliminating the need for complex electronic systems and reducing the risk of failure in harsh downhole environments.

Equipped with standardized threaded connections—commonly a 1-9/16 - 10 UN pin on the top and a 1 - 11 ½ NPT box on the bottom—the tool integrates easily into typical slickline, wireline, or coiled tubing toolstrings. The fully mechanical design enhances reliability, making it well-suited for use in conditions of high pressure, elevated temperatures, and corrosive fluids often found in oil and gas wells.

The 4” Tubing End Locator is especially valuable in wells with larger tubing sizes where accurate depth confirmation is critical to avoid operational errors. By providing a straightforward and dependable method to locate the tubing end, it supports safe and efficient well intervention, helping to reduce downtime and operational risks.
