The 6″ Butterfly Bleed Air Valve is designed to regulate the flow of compressed bleed air from the compressor section of large gas turbines, such as the LM2500. This valve uses a butterfly-shaped disc permanently attached to a robust shaft, allowing precise control over airflow to reduce pressure and temperature within the turbine system.

With an effective flow area of 19.1 square inches max, this valve accommodates higher volumes of bleed air, making it suitable for turbines with greater airflow requirements. It features a fast response time—less than 320 milliseconds for a full stroke—ensuring timely adjustments to changing operating conditions. The valve’s bearings are engineered for high cycle service, providing durability and reliability even under frequent opening and closing cycles.

The 6″ valve helps protect turbine components by managing thermal loads and maintaining optimal compressor performance, which in turn improves overall turbine efficiency and extends equipment life. It is commonly used in oil and gas applications where maintaining safe, efficient, and reliable turbine operation is critical. This valve also serves as a drop-in replacement in existing turbine systems, requiring no hydraulic or electrical modifications, simplifying installation and reducing downtime.

The LM2500+ gas turbine delivers increased power and improved efficiency by building on the proven LM2500 platform. Designed to meet the demanding needs of industrial and offshore operations, it offers a compact, reliable solution for power generation and mechanical drive applications.

The LM2500+ enhances the original LM2500 design by adding a 17-stage high-pressure axial compressor. This additional compressor stage increases airflow and raises the engine’s pressure ratio, resulting in roughly 20% more power output. The turbine uses a ring combustion chamber with advanced dry low emissions (DLE) technology, producing very low levels of NOx and CO emissions to meet strict environmental standards.

A key feature of the LM2500+ is its low-speed turbine section, which is specifically designed for offshore platforms and other space-restricted environments. This turbine’s compact size and modular design allow for easy maintenance, with split compressor casing and in-place blade replacement that reduce downtime and operational complexity. The turbine is factory-tested and pre-wired for straightforward installation, supporting both 50 Hz and 60 Hz power generation without the need for additional equipment like reducers.

Operators benefit from the LM2500+’s enhanced power and fuel efficiency, which help reduce operational costs and improve performance in applications such as combined heat and power systems, industrial power generation, underground gas storage, and gas pipelines. Its modular, space-saving design fits well in offshore installations where size and weight are critical factors.

the LM2500+ ensures continuous performance and maximizes uptime, making it a trusted solution for critical power needs across various industrial and offshore applications.

The LM2500 exhaust system is an essential part of the LM2500 gas turbine, designed to handle the hot gases produced during turbine operation. Made from high-quality stainless steel, it is built to withstand extreme temperatures and harsh conditions, ensuring long-lasting durability.

The main purpose of the exhaust system is to safely direct these hot gases away from the turbine while reducing back pressure. Back pressure is the resistance the turbine faces when pushing out exhaust gases—lower back pressure means the turbine can run more efficiently, producing more power with less stress on its components.

This exhaust system is carefully designed to match the specific needs of the LM2500 turbine, ensuring smooth and efficient gas flow. It often works together with silencers or emission controls to release gases safely into the atmosphere while meeting environmental standards.

You would look for a new or replacement LM2500 exhaust system when installing a new turbine, upgrading to improve performance, replacing worn or damaged parts, or meeting updated environmental regulations. Choosing the right exhaust system is crucial because it directly affects the turbine’s performance, reliability, and maintenance costs. A well-designed exhaust system helps keep the turbine running efficiently and reduces the chance of costly downtime—critical factors for operations in oil and gas industries where reliability and efficiency are vital.

The Single Annular Combustor (SAC) version of the LM2500+G4 is designed for oil and gas applications that prioritize consistent performance, fuel flexibility, and emissions control—such as LNG facilities, gas processing plants, and pipeline compression, both onshore and offshore.

What makes the SAC version different is its simpler combustor design compared to dual annular or premix types. The SAC uses a through-flow, venturi swirler to ensure an even temperature profile at the turbine inlet, helping extend hot section life. It features individually replaceable fuel nozzles, a durable machined-ring liner, and a thermal barrier coating for better resistance to high temperatures and corrosion. This design supports both dry operation (with higher emissions) and water or steam injection to reduce NOx when needed—making it adaptable to site-specific emission regulations.

The LM2500+G4 SAC builds on the proven LM2500+ design, with approximately 10% more power. This gain comes from increased airflow, improved internal cooling, and material upgrades—while keeping the same number of compressor and turbine stages. The 17-stage high-pressure axial compressor and the basic engine layout remain unchanged, making it easy to maintain and service.

The engine can run on a wide range of liquid and gas fuels, allowing flexibility in remote or supply-constrained locations. It achieves up to 40% thermal efficiency in simple cycle mode. Water-injected operation enables NOx emissions as low as 25 ppm (gas) and 42 ppm (liquid).

In short, the LM2500+G4 SAC is well-suited for high-power mechanical drive and power generation in harsh or remote oil and gas environments, offering a balance of power output, fuel versatility, and emissions control.

The LM2500+G4 SAC 50Hz Combined Cycle 1x1 is a gas turbine system that combines a gas turbine with a steam turbine to improve overall power generation efficiency. This configuration captures waste heat from the gas turbine exhaust and uses it to produce steam, which then drives the steam turbine, generating additional electricity. This approach helps maximize power output while making better use of fuel energy.

Building on the LM2500+ design, the LM2500+G4 increases power capability by about 10% without reducing the lifespan of critical hot section components. This is achieved by increasing airflow, enhancing materials, and improving internal cooling. Despite these upgrades, the core compressor and turbine stages, as well as most airfoil and combustor designs, remain consistent with the LM2500 model.

The LM2500+G4 features a 17-stage high-pressure compressor that raises the engine’s pressure ratio and airflow, boosting the total power output of the gas turbine to over 31 MW. It uses a Single Annular Combustor (SAC) equipped with water injection to help control emissions while maintaining stable combustion. The SAC’s simple, proven design provides uniform flame temperature and reliable operation.

This balanced system is common in industrial and energy applications where efficiency and power output must be optimized, especially under varying ambient conditions. The combined cycle setup offers a reliable and efficient solution for electricity generation in demanding environments.
